Motorola DP2400

Name: Motorola DP2400
Brand: Motorola
SKU: DP2400
Availability: InStock

£352.00 Ex VAT £422.40 Inc VAT

Versatile and powerful, MOTOTRBO combines the best of two-way radio functionality with the latest digital technology. DP2000 Series radios offer best-in-class audio in a scalable solution to meet your communication needs. Because they are also analogue interoperable, you can make the transition to digital at your own pace and budget.

This item is a licenced two-way radio. This means that you are required to have a valid OFCOM licence to use the radio in the UK. Using the radio without a licence is illegal. If you would like more information regarding OFCOM licences, please contact our service team by calling 0800 328 0100 or by emailing service@eemits.co.uk

FREE Next Day Delivery*

*Get FREE next day UK mainland delivery on orders over £50.

Programming Included

Hassle-free setup, ready to go.

Standard Features:

16 Channels	Large, textured push-to-talk button
Intelligent audio	IP55
Privacy features	2 programmable buttons

Whats in the box?

1 x Radio	1 x Battery
1 x Antenna	1 x Dust cover
1 x Belt clip

Technical Specification

Brands	Motorola
Battery Upgrades	Yes
Types of Radio	Hand Held Portable
Frequency Ranges	UHF: 403-527 MHz VHF: 136-174 MHz
Channel Capacities	16
Channel Spacings	12.5 / 20 / 25kHz
Types of Battery	NiMH 1400mAh as standard - upgrade to Li-Ion option available
Battery Life (Digital)	Approx. 10 hours
Battery Life (Analogue)	Approx. 7 hours
Frequency Stability	± 0.5 ppm
Weight of Radio (includes battery and antenna)	355 g
American Military Standards	MIL-STD-810 C / D / E / F / G
Dust & Water Instrusions	IP67
Humidity	MIL-STD-810 C / D / E / F / G
Shock & Vibration	MIL-STD-810 C / D / E / F / G
Businesses	Yes
Ip Ratings	IP55
Displays	None
Sizes	Regular
Batteries	NiMH
Encryptions	Basic
Modulating Limiting	± 2.5 kHz @ 12.5 kHz ±4.0kHz @ 20 kHz ± 5.0 kHz @ 25 kHz
Dimensions	122 x 56 x 39 mm
Features	Voice Annunciation
RX Selectivity	45dB @ 12.5 kHz 70dB @ 20/25kHz
RX Intermodulations	70 dB
TX Audio Responses	TIA603D
Esd	IEC 61000-4-2 Level 3
Rx Spurious	≥ 70 dB
Tx Digital Protocols	ETSI TS 102 361-1, -2, -3
Tx Digital Vocoder Types	AMBE+2™
Adjacent Channel Power	60dB @ 12.5 kHz 70dB @ 20/25kHz
Radio Series	DP2000
Tx Audio Disstortion	≤ 3 %
Rx Hum and Noise	-40dB @ 12.5 kHz -45dB @ 20/25kHz
Rx Audio Responses	TIA603D
Operating Temperatures	-30° C / +60°C
Storage Temperatures	-40° C / +85°C
Conducted Radiated Emissions	-36 dBm < 1GHz -30 dBm > 1GHz
Analogue Sensitivity	0.3 μV (12 dB SINAD)
Tx FM Hum and Noise	-40 dB @ 12.5 kHz -45 dB @ 20/25 kHz
Fsk Digtial Modulation	12.5 kHz Data: 7K60F1D & 7K60FXD 12.5 kHz Voice: 7K60F1E & 7K60FXE Combination of 12.5 kHz Voice & Data: 7K60F1W
Rx Radio Audio Distortions	≤ 5 %
Rx Digital Sensitivity	0.25 uV (0.19uV Typical)
Licenced	Digital
Atex	No
Rx Conducted Spurious Emissions	< - 57 dBm
Product Statuses	Enquiry Only
